Pan & Tilt

Manual speed

Pan（0.1°～200°/s）

Tilt（0.1°～180°/s）

Rotation

Pan continuously 360°, tilt 0～90° with auto-flip

Preset

128 preset

Auto-flip

Tilt down 90°, with auto-flip 180°

Patrol

up to 16 patrol

HomePosition

preset/patrol can be set

Proportional Zoom

Rotation speed can be adjusted automatically according to zoom multiples

CAM SPEC

Sensor

1/1.7" progressive scan, 8megapixel, CMOS

Frame Rate

Main Stream:8MP(3840 × 2160): Max.30fps, 2MP(1920×1080)@30fps；
Sub Stream:2MP(1920×1080) : Max. 25fps；
Third Stream: D1 (720×576): Max. 20fps

Optics Zoom

Optical 22X, f =6.5mm ~ 143 mm

Digital Zoom

Digital:16X

Angle

Angle of View (H)：58.9°~3.4°   (V)：35.2°~1.9°  (O)：72.5°~4.1°

Iris

Auto/Manual, F1.5 ~ F3.4

Auto Focus

Auto / one push / Manual

Min Illumination

Colour: 0.003 lux (F1.5,AGC ON)   0 lux with IR

Shutter

Auto/Manual, shutter time: 1 ~ 1/100000 s

Defog

Defog Digital Defog

Noise reduction

2D/3D DNR

Wide dynamic

120dB

IR Range

UP to 350m

VIDEO

Video Compression

Ultra 265,H.265, H.264, MJPEG

H.264 code profile

Baseline profile, Main Profile, High Profile

HLC

Supported

BLC

Supported

EIS

Supported

Privacy Mask

Up to 24 areas

ROI

Up to 8 areas

Motion Detection

Up to 4 areas

SMART

Behavior Detection

Intrusion, cross line, motion detection, auto tracking

Intrusion

Enter and loiter in a pre-defined virtual region

cross line

Cross a pre-defined virtual line

motion detection

Moving within a pre-defined virtual region

Recognition

Face detection、Audio detection

Intelligent Identification

Defocus, Scene Change, Object Left, Object Moving

Statistical Analysis

People counting

General Function

Watermark, IP Address Filtering, Tampering Alarm, Alarm input, Alarm output, Access Policy, ARP Protection, RTSP Authentication, User Authentication

Audio

Audio Compression

G.711

Two-way audio

Supported

Suppression

Supported

Sampling Rate

8 KHZ

Storage

Edge Storage

Micro SD, up to 256 GB

Network Storage

ANR

Network

Protocols

IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP,TLS,SSL

Compatible Integration

ONVIF(Profile S, Profile G, Profile T), API

Interface

Audio I/O

Audio cable

Input: impedance 35 kΩ; amplitude 2 V [p-p]

Output: impedance 600 Ω; amplitude 2 V [p-p]

Alarm I/O

1 IN 1 OUT

Network

1 RJ45 10M/100M Base-TX Ethernet

General

Power consumption

9W/40W(IR_LED ON)

Power supply

DC 24V/2A

POE

Support POE power supply (optional)

Temperature

 -40℃～+60℃

Installation

Wall /Corner/Pole/Pendant installation

Net weight

6.5kg

Size

Product size 336.5×230mm，     Packing size   300*300*460mm

Protection Level:

IP66 standard (outdoor dome)

TVS lightning protection, surge protection and voltage transient protection
